NT-MDT announces 12 authors of AFM-images who became winners of the ProIMAGE Contest 2012.

They are:

Au QCM substrate.Morphology of quartz crystal microbalance substrate.
Author: Mr. Shuai Zhang
Organization: Interdisciplinary Nanoscience Center
Scan size: 1 х1 µm
Probes used: NSG01
PAH_synthetic nanographene on mica
Author: Ms. Raluca Gavrila
Organization: National Institute for R&D in Microtechnologies (IMT-Bucharest)
Scan size: 2x2 µm
Probes used: ETALON HA-NC
"Polymer storm" polyhydroxy alkanoate extract
Author: Dr. Bogdan Donose
Organization: The University of Queensland/Advanced Water Management Centre
Scan size: 7x7 µm
Probes used: ETALON HA_NC
Dendrite structure formed at Plasma-Assisted Thermal Vapor Deposition of poly(ethylene) over poly(ethylene oxide)-like plasma polymer.The color contrast corresponds to the 0-10 nm range.
Author: Prof. Andrey Shukurov
Organization: Charles University in Prague, Faculty of Mathematics and Physics, Department of Macromolecular Physics
Scan size: 10x10 µm
Probes used: NSG03
Dietary supplement containing silicon structures
Author: Mr. Dmitry Podkopaev
Organization: Moscow state university of food production
Scan size: 100x100 nm
Probes used: NSG10
Collagen fibers
Author: Dr. Wojciech Chrzanowski
Organization: The University of Sydney
Scan size: 500x500 nm
Probes used: NSG01
"Bridges", wing of the butterfly
Author: Ms. Alpysbayeva Balausa
Organization: Laboratory of Engineering Profile
Scan size: 15x15 µm
Probes used: NSG01
Еopography of strontium titanate (SrTiO3) substrate which was mechanically polished and subsequently chemically etched.
Author: Mr. Filimon Andrei
Organization: INCDFM Bucharest, Magurele
Scan size: 5x5 µm
Probes used: NSG03
A lipophilic guanosine derivate (2'O,3'O-Isopropylidene-50-decanoylguanosine) deposited from chloroformic solution on a glass substrate. Lipophilic guanosine derivates exhibit a rich supramolecular chemistry in organic solutions, on surfaces and in the solid state and can be used as dispersion agent for carbon nanotubes.
Author: Dr. Ilona Kopf
Organization: School of Chemistry/CRANN, Trinity College Dublin
Scan size: 4.1х4.1 µm
Probes used: NSG01
Water in mica (Phase)
Author: Mr. Reinier Oropesa-Nuñez
Organization: CEAC
Scan size: 10х10 µm
Probes used: NSG10
Ge(Si) quantum dots
Author: Dr. Mikhail V. Shaleev
Organization: Institute for Physics of Microstructures RAS
Scan size: 2x2 µm
Probes used: NSG01
Bacterial magnetic nanoparticles assembled in chain isolated from new freshwater bacteris Magnetospirillum SO-1
Author: Dr. Denis Kurek
Organization: Centre "Bioengineering" RAS
Scan size: 1.5x1.5 µm
Probes used: NSG10

Our heartiest congratulates to the winners! The winners will get Diplomas and reward points in the bonus program of NanoBOND Club!

NT-MDT wishes everyone further brilliant results!
